We are a leading specialist in the power transmission industry, please feel free to contact us regarding any planetary gearbox requirements. It’s this combination of engineering excellence and ongoing innovation that keeps Lancereal at the forefront of gearbox technology. Every gearbox we supply will deliver years of trouble-free performance. We use our experience and insight to identify and supply a suitable planetary gear solution that’s cost-effective and reliable.
We start each project by developing a deep understanding of the application, the speeds, torque and function of the machine. At Lancereal, we have a consultative approach to design. It’s a careful balance between size, efficiency, performance and cost. The choice of planetary gearbox, its size and gearing ratio should be defined by the outcome. How Do I Know What Planetary Gearbox I Need?
We are also able to incorporate hydraulic, dynamic and electromagnetic braking within our range of planetary gearboxes. We’re able to provide single, double or triple stage units to suit any application. Our planetary gearboxes are available in 1-speed and 2-speed options. Planetary gear sets can be used in stages, which offer a variety of transmission ratio options that can be tailored to your requirements. At Lancereal, we provide planetary gear sets for use in industrial and mobile applications. Planetary gear sets can be used for a variety of purposes. Our spindle drive planetary gears can deliver up to 113,000Nm torque. Spindle output planetary gearboxes work in the same was as shaft outputs however, the output is supplied as a flange. Our range of shaft output gears can deliver up to 113,000Nm torque.
The housing of the gearbox is fixed directly to the machine with the output being a rotating shaft. The ring gear is held stationary with the rotating carrier delivering drive to the shaft. In shaft drive gearboxes, the sun gear drives the surrounding planetary gears which are housed in a rotating carrier. Wheel drive planetary gears can deliver up to 332,000Nm torque. By mounting the wheel directly to the gearbox, the size of the assembly can be minimised. The wheels can be mounted over the housing of the gearbox. When the sun gear is driven, the planet gears rotate the outer ring gear. In a wheel drive planetary gearbox, the sun gear drives the surrounding planetary gears which are fixed to a carrier. Approximately 97% of the energy input is delivered as an output.Īt Lancereal, we offer three different types of planetary gearbox, a wheel drive, shaft output and spindle output. The simple design is a highly efficient and effective way of transferring power from a motor to an output. It drives several rotating external gears which increases the torque. The central sun gear takes a high-speed, low-torque input. The load from the sun gear is distributed to several planetary gears which can either be used to drive an outer ring or a shaft or spindle. Planetary gearboxes can be powered by either electric motors, hydraulic motors or petrol or diesel combustion engines. For higher ratios we can offer double or triple stages. The three components make up a stage within a planetary gearbox. The sun gear that sits in the centre (central gear). In this article, we explore the principles of operation, how planetary gears work, and where you might find them.Ī simple planetary gear set is made up of three main components:ġ. Today, engineers use planetary gears in applications that demand high torque density, operational efficiency and durability. The simple configuration of a central drive and orbiting gears was developed thousands of years ago to model the movements of the planets. Planetary gears are at the heart of modern engineering and are used in gearboxes that power everything from basic plant machinery to cutting-edge electric vehicles.
